Your Position: Home > Products > Supporting High-end

New Features:
1. High precision, good stability. 2. clamping range can be adjusted freely. 3. Strong torsionally rigid tapping. 4. quick, easy loading and unloading. 5. A wide range of applications: Tapping machines, drilling machines, high-speed lathes, CNC machining centers and other reversible spindle.

Taps holding method:
Turn the chuck Qiantao, retractable jaws to be slightly larger than the tap shank diameter, fitted with taps, then turn the double-headed screws, through the observation hole observed the two eccentric nut on light-headed screws light grip tap Quartet, then rotate Qiantao, clip firmly tap wrench with matching clamping finally locking screw with a hex-headed wrench, clamp tap Quartet.

Product performance:
the product has an adjustable clamping range, within the clamping range of British, American, Metric and special sizes can be used non-standard tap; the overall use of the goods of high quality materials, the overall quenching, with high precision, high torque, high durability and other characteristics.
Scope:
commonly used in the "West" brand, such as desktop and pneumatic tapping machine, electric and other types of tapping machine, and can be used for lathes, milling machines, CNC and other rigid tapping.
